Aftermarket Assassins Can-Am Maverick X3 Launch Control Module

Aftermarket Assassins Can-Am Maverick X3 Launch Control Module

Please make sure you carefully read over the entire description before purchasing

Launch control for your X3! This module utilizes a momentary switch to be engaged and allow for launch control to build boost at the starting line for drag racing, or other types of racing.... and just plain fun. The amount of boost you build at the line depends on your CVT clutch engagement and RPM settings in the launch control module. The higher the engagement RPM, the more boost you can build.

To use this module you want our clutch kit, or any other clutch kit with a higher stall than factory. Read below on your options:

• 120HP, 154HP & 172HP base models with our S2 clutch kit will have a purple/blue primary spring which engage around 2000 RPM. If you want higher engagement with this kit, choose our purple/black primary spring for a 2300 RPM engagement, or the purple/yellow spring for 2500 RPM launch. Keep in mind, If using the purple/yellow spring your peak RPM will go up by roughly 200 RPM. The purple/black spring will not change peak RPM.
• 120HP, 154HP & 172HP base models with our S3 clutch kit (all 6 AA primary weights) will have a purple/blue primary spring which engage around 2000 RPM. If you want higher engagement with this kit, choose our purple/black primary spring for a 2300 RPM engagement, or the purple/yellow spring for 2500 RPM launch. Keep in mind, If using the purple/yellow spring your peak RPM will go up by roughly 200 RPM. The purple/black spring will not change peak RPM.
• 2020 X3 RR 195HP models with our S2 or S3 clutch kit normally use our green primary spring with an engagement of 2000 RPM. If you'd like a higher RPM stall you can use the purple/blue primary spring for a 2300 RPM engagement, or the purple/black spring for 2500 RPM engagement, or the purple/yellow spring for 2700 RPM launch. Keep in mind, If using the purple/yellow spring your peak RPM will go up by roughly 200 RPM. The purple/blue spring nor the purple/black spring will change peak RPM.

Knowing what launch RPM to choose: Launch control should always be used with caution and set up properly for your clutch engagement. Clutch engagement can be tested by having the vehicle in high range, then slowly pressing the gas pedal down while looking at RPM. The RPM where the vehicle starts to move is your engagement RPM. Test on flat ground a few times to make sure you get consistent results. We are looking for launch control to be right at engagement RPM. It's best to check this before purchasing the LCM, if possible. Once you receive the module, we suggest double checking your engagement RPM/launch RPM is correct by using launch control without holding the brake. The vehicle should just barely want to move if set up properly. If the vehicle is lurching and really trying to move, you need to get a higher stall spring, a fresh clutch spring, or lower launch RPM.

To engage launch control, start the vehicle and make sure the vehicle is at an idle (module will not engage launch mode if vehicle is at over 1500 RPM). Now press and hold the launch switch while giving the vehicle throttle. Go full throttle and the vehicle should hold at your desired launch RPM. Most will hold the brake at the same time to keep vehicle from creeping forward. When ready to accelerate, drop the brake and launch switch at the same time and the vehicle will..... well launch!

Adjusting Launch RPM: For more information on this, go to our tech section and read our post on using/adjusting your LCM. Basic rundown is: Download the DynoJet C3 software (from dynojet.com/downloads), plug in your LCM via the supplied USB, then go to Configure, "Feature Enables and Inputs Selections" then click "Launch Control" and you'll see target RPM. Change this value as desired, click "Send" up top (green upward arrow), and that's it.

Must have AA tuning with updated tunes for the LCM to work correctly and not throw a misfire code. See note below.

Tune updates are REQUIRED for those that purchased their tunes from us before 11/1/2020. We had to update our tunes to desensitize misfire or the vehicle would go into limp mode. We will need to update tunes to the latest version. After you purchase we'll email asking for your PV_INFO file with instructions. If you are currently purchasing our tunes or purchased our tunes/tuner after 11/1/2020 then you can select the No, I don't need my tunes updated option in the drop down.

Features:

• Wicked acceleration!
• With only brake boosting, the manifold pressure in the plenum is not very high and this can be damaging to clutches and belts. This 2 step launch control builds boost at the line giving you the competitive edge for acceleration.
• For playing around/fun, using launch control is best used at your engagement RPM to prevent clutch/belt issues.
• For drag racing, launch control is best to have between 200-500 RPM above engagement point. This requires using more brake, and will load the motor/turbo for higher boost pressure. This is harder on the belt and clutches, but is okay for when used in moderation.
• Developed with DynoJet with our own wiring, switch, programming, tune and tech support

Note:

• AA custom tunes for your PV3 device are required to work with our custom tuned/wired LCM on ME17 ECUs. These ECUs were found on 2017 154hp, 2018-2022 135hp, 2018-2021 172hp, & 2020 X3 RR 195hp
• MG1 ECUs: 2021+ RR 195/200hp models, or 2023+ X3 135hp models cannot be flashed at this time, but normally have no issues running OEM tuning with launch control. When running the LCM on these models, you run the slight risk of hitting misfire detection, but in our testing, this has not been an issue.
• Launch RPM is programmed by us, but can also be changed via Windows computer and DynoJet C3 software by the end user.

Fitment:

• Fits all 2017+ Can-Am Maverick X3 Models (120HP, 135HP, 154HP, 172HP, 195HP RR, 200HP RR)
